Geometric Panels

Geometric Sonic Panels are highly aesthetic and popularly customized. They offer an elegant and economical sound absorption solution. Geometric Sonic Panels offer a variety of sizes and shapes available in over 100 colors. They provide ideal results for noise control and are impressively decorative which allows them to accommodate to any workable environment.

These Glass Fiber panels are covered with an acoustically transparent and very decorative fabric, the fabrics allow for the variety in colors as well as variety in the texture of the fabric. The fabrics that are used are offered in an assortment of different textures. Geometric Sonic Panels are ideal for spaces with high reverberation time.

Our Geometric Sonic Panels are designed to improve sound quality and to provide a decorative look within a room.

🔥 CLASS-A FIRE RATED 🔥

Usage

Geometric panels can be installed in Lobby, Radio Studios, Recording Studios, Schools, Offices, Restaurants, Hotels, Houses of Worship, or any other facility with the need of noise control.

Clear
Categories: ,

Manufacturing

Manufactures Standard panel construction consisting of facing material stretched over front face of edge-framed, dimensionally stable, rigid glass-fiber board core and borders or attached to edges and back of frames and complying with the following requirements:

  1. Facing Material: Stretched Panel Fabric Guilford of Maine FR 701 Style 2100 (or other fabrics of similar characteristics)
  2. Nominal core Density: 4-7 lbs /Ft3 (64 – 112 Kg/m3)
  3. Framing: Manufacturer´s standard metal or wood framing system. No plastic frame.

Acoustic Performance

Acoustic Performance 1″ Thick Noise Reduction Coefficient 0.86
Absorption Coeff.(α) Frequency (Hz)
0.16 125
0.27 250
0.85 500
1.13 1000
1.2 2000
1.21 4000
0.86 NRC
Acoustic Performace 2″ Thick Noise Reduction Coefficient 0.86
Absorption Coeff.(α) Frequency (Hz)
0.24 125
0.82 250
1.26 500
1.32 1000
1.23 2000
1.17 4000
1.16 NRC

Nominal Overall Dimensions

Panel Thickness: Manufacturer´s Standard
  • 2″ inches Rigid Fiber-Glass
  • 1″ inches Rigid Fiber-Glass
  • Panel Widths: 24″, 48”, or custom
  • Panel Height: 2’, 4’, 6´, 8´, 9´, & 10´
  • Edge detail: Square or custom

Weight

Nominal Core Density 4 – 7lbs/ ft3 ( 64 – 112 kg/ m3)

Fire Resistance

The fiberglass acoustic panels that we use provide very good fire-resistant properties. It shows a flame spread of 25 or less as per ASTM E 84 by UL Flame Spread: 25 (class A). Smoke developed: 450 or less, smoke developed: 50.

Cleaning and Maintenance

These panels are designed for long term use in building environments with minimal maintenance. The panels, however, can be vacuum cleaned as per customer desire; additionally, any marks may be cleaned with a damp cloth/ wipe.

Installation

Download our installation PDF or view our installation video. For more support on installation please call or email us.
